This fiber to fiber converter card is a protocol independent device that supports data rates from 100Mbps up to 2.5 Gbps. Installed in an ION chassis it provides reliable and cost-effective conversion between single mode and multimode fiber while also providing wavelength conversion in CWDM applications. As an SFP based device this any-rate to similar-rate converter offers great application flexibility. Supported protocols fiber connectors and transmission distances are determined by the SFP module used on the converter.
Specification:
Device Type: Fiber media converter
Form Factor: Plug-in card
Connectivity Technology: Wired
Data Link Protocol: Ethernet FDDI Fast Ethernet InfiniBand Fibre Channel 2Gb Fibre Channel SONET ESCON
Data Transfer Rate: 2.5 Gbps
Line Rate: OC-48 /OC-12 /OC-3
Remote Management Protocol: DMI
Status Indicators: Power link OK
Features: CWDM Jumbo Frames support Digital Diagnostics Link Pass-Through Automatic Link Restoration
Interfaces: 2 x - SFP
MTBF: 687000 hour(s)
Compliant Standards: FCC Class A certified EN55024 EN55022 Class A MSA
Power Consumption Operational: 3 Watt
Width: 3.2 in
Depth: 6.5 in
Height: 1 in
Service & Support: Limited lifetime warranty
Service & Support Details: Limited warranty - lifetime
Min Operating Temperature: 32
Specification:
Device Type: Fiber media converter
Form Factor: Plug-in card
Connectivity Technology: Wired
Data Link Protocol: Ethernet FDDI Fast Ethernet InfiniBand Fibre Channel 2Gb Fibre Channel SONET ESCON
Data Transfer Rate: 2.5 Gbps
Line Rate: OC-48 /OC-12 /OC-3
Remote Management Protocol: DMI
Status Indicators: Power link OK
Features: CWDM Jumbo Frames support Digital Diagnostics Link Pass-Through Automatic Link Restoration
Interfaces: 2 x - SFP
MTBF: 687000 hour(s)
Compliant Standards: FCC Class A certified EN55024 EN55022 Class A MSA
Power Consumption Operational: 3 Watt
Width: 3.2 in
Depth: 6.5 in
Height: 1 in
Service & Support: Limited lifetime warranty
Service & Support Details: Limited warranty - lifetime
Min Operating Temperature: 32
