The ION C3110 device provides an interface allowing users to integrated fiber optic cabling into 1000Base-T copper environments.
Specification:
Device Type: Media converter
Form Factor: Plug-in module
Connectivity Technology: Wired
Cabling Type: 1000Base-LX 1000Base-T
Data Link Protocol: Gigabit Ethernet
Data Transfer Rate: 1 Gbps
Optical Wave Length: 1310 nm
Max Transfer Distance: 6.2 miles
Status Indicators: Link activity power
Features: Auto-negotiation AutoCross Far End Fault (FEF) firmware upgradable
Compliant Standards: IEEE 802.3z IEEE 802.3ab
Interfaces: 1 x Ethernet 1000Base-T - RJ-45 female
Compatible Slots: 1 x expansion slot
Compliant Standards: FCC Class A certified EN 60950 EN55024 EN55022 Class A
Power Consumption Operational: 3.6 Watt
Width: 0.9 in
Depth: 6.5 in
Height: 3.4 in
Service & Support: Limited lifetime warranty
Service & Support Details: Limited warranty - lifetime
Specification:
Device Type: Media converter
Form Factor: Plug-in module
Connectivity Technology: Wired
Cabling Type: 1000Base-LX 1000Base-T
Data Link Protocol: Gigabit Ethernet
Data Transfer Rate: 1 Gbps
Optical Wave Length: 1310 nm
Max Transfer Distance: 6.2 miles
Status Indicators: Link activity power
Features: Auto-negotiation AutoCross Far End Fault (FEF) firmware upgradable
Compliant Standards: IEEE 802.3z IEEE 802.3ab
Interfaces: 1 x Ethernet 1000Base-T - RJ-45 female
Compatible Slots: 1 x expansion slot
Compliant Standards: FCC Class A certified EN 60950 EN55024 EN55022 Class A
Power Consumption Operational: 3.6 Watt
Width: 0.9 in
Depth: 6.5 in
Height: 3.4 in
Service & Support: Limited lifetime warranty
Service & Support Details: Limited warranty - lifetime
