The ION C3210 device provides an interface between 10/100/1000Base-T ports and 1000Base-SX/LX ports allowing users to integrated fiber optic cabling into 10/100/1000Base-T copper environments.
Specification:
Device Type: Media converter
Form Factor: Plug-in module
Connectivity Technology: Wired
Cabling Type: 10Base-T 1000Base-SX 1000Base-T 100Base-X
Data Link Protocol: Ethernet Fast Ethernet Gigabit Ethernet
Data Transfer Rate: 1 Gbps
Optical Wave Length: 850 nm
Remote Management Protocol: RMON DMI
Max Transfer Distance: 1800 ft
Status Indicators: Link activity power
Features: Auto-negotiation VLAN support auto-uplink (auto MDI/MDI-X) manageable IPv6 support AutoCross firmware upgradable Link Fault Pass Through function (LFP) Quality of Service (QoS) Jumbo Frames support
Compliant Standards: IEEE 802.3 IEEE 802.3u IEEE 802.3z IEEE 802.1Q IEEE 802.3ab IEEE 802.1p IEEE 802.3p IEEE 802.3xy
Interfaces: 1 x Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 female
Compatible Slots: 1 x expansion slot
Compliant Standards: FCC Class A certified CISPR 22 Class A EN55024 EN55022 Class A
Width: 0.9 in
Depth: 6.5 in
Height: 3.4 in
Service & Support: Limited lifetime warranty
Service & Support Details: Limited warranty - lifetime
Specification:
Device Type: Media converter
Form Factor: Plug-in module
Connectivity Technology: Wired
Cabling Type: 10Base-T 1000Base-SX 1000Base-T 100Base-X
Data Link Protocol: Ethernet Fast Ethernet Gigabit Ethernet
Data Transfer Rate: 1 Gbps
Optical Wave Length: 850 nm
Remote Management Protocol: RMON DMI
Max Transfer Distance: 1800 ft
Status Indicators: Link activity power
Features: Auto-negotiation VLAN support auto-uplink (auto MDI/MDI-X) manageable IPv6 support AutoCross firmware upgradable Link Fault Pass Through function (LFP) Quality of Service (QoS) Jumbo Frames support
Compliant Standards: IEEE 802.3 IEEE 802.3u IEEE 802.3z IEEE 802.1Q IEEE 802.3ab IEEE 802.1p IEEE 802.3p IEEE 802.3xy
Interfaces: 1 x Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 female
Compatible Slots: 1 x expansion slot
Compliant Standards: FCC Class A certified CISPR 22 Class A EN55024 EN55022 Class A
Width: 0.9 in
Depth: 6.5 in
Height: 3.4 in
Service & Support: Limited lifetime warranty
Service & Support Details: Limited warranty - lifetime
